SCS-X SLIDING SYSTEM

Material: Aluminium – glass
Used glass types: Temperred 8-10 mm / Laminated 4+4 – 5+5
Color options for profiles: RAL- Eloxal- special colors
Color options for accessories: Color options for plastic accessories are black, grey and white
Max. Panel width: 1000 mm
Max. Panel height: 2300 mm

Profile System

  • Optionally with or without vertical panel frames
  • Parking variations is possible left, right or both side by no treshold bottom profile
  • 2 types of bottom and uppes profiles are available. These are 3 and 5 rails

Accessories

  • All fittings are concealed within the profiles
  • Low-meintenance, non-corroding and failsafe fittings
  • Inside and/or outside locking possible
  • Left and right side locking possible owing to new desing lock
  • Stainless steel and/or aluminium handles eligible optionally
  • Optionally grey and black colour accessories are available
  • Metal covers are standart (paintable to any colour)

Assembly

  • Every panel fitted low-maintenance and non-corroding rollers
  • Polyamid coated and high quality rollers are used
  • Low noise, low corrosion and high resistance to cold and hot affect

Sealing and Ventilation

  • The gaps between the panes are 3-5 mm
  • Effacement the gaps between the panes with Using with aluminium profiles
  • Brush gaskets are fitted horizontally to top and on the vertical frame inside and outside
  • This system is more suitable for partition of the offices and interior of the houses

Glass

  • 8 or 10 mm tempered safety glass panes./li>
  • Glass panes are fixed as safely to bottom of the panel profiles fasten with silicone adhesive

Colour Options

  • There are 4 kind of standard colour options as ;Eloxal, white, wooden and pres (without colour)
  • As an optional, able to paint with all the  RAL colours
